EMI in Industrial Automation
Electromagnetic Interference, known as EMI shortly, is the disturbance or disruption caused in an electronic device’s operation due to the radio frequency spectrum of another electronic device in the vicinity of which it occurs. For instance, the sparking on the motor brushes, tension circuits switching, activation of inductive and resistive loads, activation of switches, automotive ignitions, atmospheric discharges, and even the electrostatic discharge between persons and devices, microwave devices, mobile communication devices, etc. These may cause an overload, which in turn may cause a high impact on a communication network. This commonly occurs in industries and factories as is very frequent because of the use of large machines such as welding instruments, motors (MCCs), and digital networks and computers in these areas’ vicinity.
EMI is largely problematic as it can cause slow degradation of equipment and its components. Other problems that can be traced to EMI are communication failures between devices of the same equipment network and/or computers, alarms produced without explanation, action on relays that do not follow the logic, without being commanded, in addition to the burning of electronic components and circuits, etc. Due to bad grounding and shielding, it often causes noises in power source lines.
To minimize the impact of EMI, it is important to consider the topology and the distribution of the wiring, types of cables, and protection techniques. The cables can work as a transmission system in high frequencies; with crossed and confused lines, they can reflect and scatter energy from one circuit to another. Hence it is crucial to keep the connection in good condition. Inactive connectors can operate before RF detectors by developing resistance.
Below are some general guidelines to limit EMI effects-
- When it comes to technical problems, do not be neglectful, imprudent, irresponsible, or incompetent. Try to get to the root of the problem or get immediate help from an expert.
- Be well informed about the system you are working with before starting work as each plant has its own safety details.
- Adhere to the safety practices and physical references that are in place for the area.
- Keep the terminals and wiring from contacting each other and act safely, as an electric shock may occur due to high voltage.
- If any equipment is installed incorrectly, it may damage the system’s performance and be a potential source of danger and accidents. Therefore it is advisable to get the installation, operation, and maintenance jobs done by trained professionals.
Take note of the standards that guarantee adequate signal levels and the safety demanded by the application before beginning the automation project.
READ MORE ARTICLES :
- Advantages and disadvantages of new technology in cars
- The best topic you can write in your research high school essay
- SEO News Roundup: Google Stops Using DMOZ
- BRIEF-New Focus Auto Tech updates on the possible delisting of Taiwan depository receipts
- Top 5 Reasons Why You Should Choose Carpet Cleaning Services
Preventive maintenance actions must be taken annually to check each on the grounding system to ensure each connection’s quality concerning robustness, reliability, and low impedance while also checking that there is no corrosion and contamination.
